Review of the gaming laptop Acer Predator Helios 300 (PH315-53): a universal set of gamers Review of the gaming laptop Acer Predator Helios 300 (PH315-53): a universal set of gamers
Contents show

The Predator Helios 300 series of laptops has seen a significant transformation in 2019 – we noted this in detail in our review of the 17-inch PH317-53 model. The laptop has become better in many respects and deservedly earned a positive rating from the site’s test lab. As you might guess, the PH315-53 version has a 15-inch screen, but otherwise offers the same features, specifications and gaming performance.





 Acer Predator Helios 300 (PH315-53)

Acer Predator Helios 300 (PH315-53)

⇡#Technical characteristics, equipment and software

Let’s reiterate: versions marked PH317-53 are laptops equipped with a 17-inch IPS matrix; PH315-53 are 15″ models. One of these is what we are talking about today. The table below shows all possible combinations of hardware for a more compact and lighter version of the Predator Helios 300.



Acer Predator Helios 300 (PH315-53)
Primary Display 15.6″, 1920 × 1080, IPS, 144Hz
CPU Intel Core i7-10750H
Intel Core i5-10300H
Video card NVIDIA GeForce RTX 2070 Max-Q 8GB GDDR6
NVIDIA GeForce RTX 2060 6GB GDDR6
NVIDIA GeForce GTX 1660 Ti 6GB GDDR6
RAM Up to 32GB DDR4-3200
Install Drives 2 × M.2 in PCI Express x4 3.0 mode
1 × SATA 6Gb/s
Optical Drive None
Interfaces 1 × USB 3.1 Gen2 Type-C
3 × USB 3.1 Gen1 Type-A
1 x 3.5mm mini jack
1 x HDMI
1 × mini-DisplayPort
1 × RJ-45
Built-in battery 66 Wh
External power supply 280W and 230W
Dimensions 363 × 255 × 23 mm
Notebook weight 2.5kg
Operating system Windows 10 Home
Warranty 1 year
USD price 2200



By the way, we tested one of the most sophisticated modifications of Helios“. The tested sample (labeled PH315-53-75AB) is equipped with a 6-core Core i7-10750H and GeForce RTX 2070 Max-Q graphics, 24 GB of RAM, as well as a terabyte hard drive and solid state drive. The version without pre-installed Windows at the time of writing cost an average of $2,200 in Moscow retail.

The Killer E2500 gigabit controller is responsible for the wired network in the laptop, and the Killer Wireless-AX 1650i is responsible for the wireless connection. The updated Wi-Fi module supports IEEE 802.11b / g / n / ac / ax standards with a frequency of 2.4 and 5 GHz and a maximum bandwidth of up to 2.4 Gb / s and Bluetooth 5.0.

The laptop comes with an external power supply with a power of 230 W and a mass of about 600 grams.

⇡#Appearance and Input Devices

All Acer Predator series gaming computers have a recognizable design: it is black with splashes of white and blue; these are strict, chopped and to some extent brutal forms; this is a recognizable logo – in laptops, by the way, it is highlighted during operation. The build quality of the laptop, when compared to the 17-inch version, has not changed and can still be considered excellent, as well as the materials used. The display cover and the area around the keyboard of “Helios” are made of metal, the rest of the body is made of matte plastic.

The dimensions and weight of the Predator Helios 300 are standard. The laptop weighs 2.5 kg, and such a load can be carried with you in a backpack if there is an urgent need for it. The case thickness is 25 mm. Naturally, “Helios” corresponds to all the fashion trends in laptop building: the screen side frames are 9 mm thick.

The cover of the hero of the review opens about 150 degrees, and its hinges are rather tight, but it can be easily opened with one hand.

All I / O ports of the laptop are located on the sides. At the back, only the connector for connecting an external power supply was “hidden”. Unfortunately, the laptop does not support USB Power Delivery – readers are asked to note the presence of this feature in gaming laptops.

On the left, the laptop has an Ethernet port, two USB 3.1 Gen1 A-types, and a 3.5mm headset jack. On the right are HDMI and mini-DisplayPort outputs, another USB 3.1 Gen1 and a USB 3.1 Gen2 C-type connector. Having grieved about the missing card reader, in general, I state that the necessary set of ports is still in the laptop.

The photo above clearly shows that a very rare guest visited the test lab. Yes, the presence of a digital block in modern gaming “tags” is becoming a real curiosity, but the Predator Helios 300 has it.

The keyboard layout of the review hero completely repeats the one used in the 17-inch version of Helios”, even the size of all buttons has not changed. So again I had to get used to the tiny F1-F12 row, as well as the not very large right Shift and Tab.

The keyboard has 4-level (in terms of brightness) RGB backlighting. Moreover, in the PredatorSense program, you can set up four different glow zones or use one of five dynamic profiles, such as Breath, Wave, Scale, Shift and Neon.

In general, playing and working with text behind the keyboard “Helios” turned out to be quite convenient.

Naturally, the 720p webcam, which is equipped with all Predator Helios 300 regardless of the screen diagonal, has not disappeared. Its image quality, however, is only good enough for warm tube video calls with family and friends. For streaming, it is better to buy a separate camera.

⇡#Internal design and upgrade options

The big Predator Helios 300 was easy to take apart, and I honestly didn’t expect to have trouble taking apart the 15-inch version. The method of removing the bottom was simple: unscrew all the available screws, gently pry the edge of the removable plate with something plastic and slowly detach it from the rest of the case. That’s just something went wrong – the bottom could not be separated!

Nevertheless, intelligence reports that the laptop’s cooling system does not differ from that used in the 17-inch “Helios“, and consists of four copper radiators, three heat pipes yes pairs of fans of tangential type. We will definitely check the effectiveness of its work, but so far the presence of large black copper plates attracts attention.

Fans blow heated air from the back and side of the case. The manufacturer claims that the AeroBlade 3D impellers have a unique blade shape that provides maximum air exchange inside the laptop case. Each of the 59 blades is 0.1mm thick, all-metal, and has a complex profile that Acer says reduces turbulence and noise.

The laptop has good upgrade options. The test sample has 24 GB of DDR4-3200 RAM, recruited by two modules of 8 + 16 GB. A Western Digital WDC PC SN730 SSD is installed in one of the two M.2 2280 slots, and a Seagate ST1000LM049-2GH172 hard drive is inserted into the 2.5-inch drive slot. Over time, it will be possible to install another fast SSD in an empty M.2 port, and no one forbids changing the HDD. Accordingly, an 8-gigabyte DDR4 memory bar can be replaced with the same module, but larger.

⇡#Test Methodology







The updated testing methodology for gaming laptops puts even more emphasis on PC gaming. Laptop performance was measured using various software.

Games (Full HD resolution):

  • Counter Strike: Global Offensive. DirectX 9. Map Benchmark. Maximum quality, MSAA 8x + FXAA.
  • World of Tanks enCore. DirectX 11. Benchmark. Ultra mode, TSSAA HQ.
  • Dota 2. DirectX 11. Match recording. Maximum quality.
  • The Witcher III: Wild Hunt. DirectX 11. Novigrad and surroundings. Maximum quality.
  • GTA V. DirectX 11. Built-in benchmark (last scene). Maximum quality, FXAA + 2x MSAA, advanced quality settings on, 16x AF, image resolution scaling off
  • The Elder Scrolls V: Skyrim Special Edition. DirectX 11. Riverwood and surroundings. Maximum quality, TAA. No mods.
  • Total War Three Kingdoms. DirectX 11. Built-in benchmark. Max mode, TAA.
  • Far Cry New Dawn. DirectX 11. Built-in benchmark. Maximum quality, HD textures – on, TAA.
  • Assassin’s Creed Odyssey. DirectX 11. Built-in benchmark. Highest mode.
  • Metro: Exodus. DirectX 12. Built-in benchmark. Ultra Mode
  • Battlefield V. DirectX 12. The Last Tiger mission. Ultra Mode, TAA, DXR Off
  • Shadow of the Tomb Raider. DirectX 12. Built-in benchmark. Maximum quality, DXR – off, TAA.
  • Deus Ex: Mankind Divided. DirectX 12. Built-in benchmark. Maximum quality, 2x MSSA.
  • Gears 5. DirectX 12. Built-in benchmark. Ultra Mode
  • Red Dead Redemption 2. Vulkan. Built-in benchmark (last scene). Maximum quality (advanced settings – off), TAA.
  • DOOM Eternal. Vulcan. Beginning of the game. Ultra Mode

The gaming performance of the laptop was determined using the well-known MSI Afterburner program. It allows you to get the rendering time of each frame. The use of the 99th percentile instead of the minimum frames per second is due to the desire to clean up the results from random bursts of performance that were provoked by reasons not directly related to the operation of the main components of the platform.

Testing the laptop in games and applications was carried out with the activation of the fastest mode suitable for these tasks.

Applications:

  • Corona 1.3. Testing rendering speed using the renderer of the same name. Measures the build speed of the standard BTR scene used to measure performance.
  • Blender 2.83. Determination of the final rendering speed in one of the popular free packages for creating three-dimensional graphics. The duration of building the final model pavillon_barcelona_v1.2 from Blender Benchmark is measured.
  • x265 HD Benchmark. Testing the speed of video transcoding to H.265/HEVC format. The tables and graphs show the average integer value obtained after five runs of the test.
  • CINEBENCH R20. Performance measurement of photorealistic 3D rendering in CINEMA 4D animation package, CPU test. The tables and graphs show the average integer value obtained after five runs of the test.
  • Adobe Premiere Pro 2020. Рендеринг проекта в разрешении 4K.
  • Topaz Video Enhance AI v1.2.3. Performance testing in an AI-based program to improve video detail. The test uses the original video at 1280 × 720 resolution, which is scaled up by 150% using the Artemis-HQ model: P, HQ, MC.

Comprehensive benchmarks:

  • Futuremark PCMARK10 Professional Edition 2.1.2177. Testing in Essentials scenarios (typical work of an average user: launching applications, surfing the Internet, video conferencing), Productivity (office work with a text editor and spreadsheets), Digital Content Creation (creation of digital content: photo editing, non-linear video editing, rendering and 3D visualization -models).
  • 3DMark Professional Edition 2.11.6846. Testing in Time Spy and Fire Strike scenes.
  • Unigine Superposition Benchmark. 1080p Extreme testing.

Notebook testing in resource-intensive applications was carried out in the default mode without any adjustment of the parameters of the central processor and cooler.

Display testing is performed using the X-Rite i1Display Pro colorimeter and the DisplayCAL 3 application.

The battery life of the laptop was tested in two modes. The first load option – web surfing – involves alternately opening and closing the tabs of the Computeruniverse.ru and Unsplash.com sites with an interval of 30 seconds. For this test, the current version of the Google Chrome browser at the time of testing is used. In the second mode, video in .mkv format and Full HD resolution is played in the built-in player of Windows OS with the repeat function activated. In all cases, the same display brightness was set to 200 cd / m2, and the keyboard backlight (if any) and the sound were turned off.

In games and other applications, the results of the following laptops are considered:



Test Participants
Model Screen Processor RAM Graphics Drive Battery
MSI GS66 Stealth 15.6”, 1920 × 1080, IPS (IGZO) Intel Core i7-10750H, 6/12 cores/threads, 2.6 (5.0) GHz, 45W 16 GB DDR4-2666 Dual Channel NVIDIA GeForce RTX 2060 6GB GDDR6 SSD, 1TB 99 Wh
ASUS ROG Zephyrus Duo 15 15.6”, 3840 × 2160, IPS Intel Core i9-10980HK, 8/16 cores/threads, 2.4 (5.3) GHz, 45W 32GB DDR4-3200 Dual Channel NVIDIA GeForce RTX 2080 SUPER Max-Q 8GB GDDR6 2TB SSD 90 Wh
Acer Predator Helios 300 (PH315-53) 15.6”, 1920 × 1080, IPS Intel Core i7-10750H, 6/12 cores/threads, 2.6 (5.0) GHz, 45W 24 GB DDR4-3200 Dual Channel NVIDIA GeForce RTX 2070 Max-Q 8GB GDDR6 SSD, 1TB
HDD, 1 TB
58 Wh



⇡#Display and Sound

The 15-inch Predator Helios 300 models use an IPS panel with a vertical refresh rate of 144 Hz and a response time of 3 ms. We are talking about NV156FHM-N4K from BOE. Screen test results are shown in the table. In general, the Helios display is well suited for gaming and watching movies (high frequency and contrast, fast response), but it is unlikely to be suitable for those who are professionally involved in photography and video.



Acer Predator Helios 300 (matrix – BOE NV156FHM-N4K)
Minimum brightness 21 cd/m2
Max brightness 314 cd/m2
Color temperature 7680K
Contrast 1122:1
sRGB gamut 85.2%
Adobe RGB color gamut 62.2%
Grey Scale Deviation: Average (Maximum) 0.32 (0.97)
ColorChecker24 test deviation: mean (maximum) 0.49 (5.7)
Viewing angles As stated
Glow effect Present
PWM Unseen at all brightness levels



Overall, I liked the sound of the Predator Helios 300, and it’s almost the same as what I heard when testing the 17-inch version. This is a clean, smooth and loud sound without wheezing and extraneous noise. Mids and highs sound quite natural and voluminous.

⇡#Efficiency of the cooling system

The Predator Helios 300 has three operating modes: Normal (default), Fast and Extreme. The difference in performance between the first and second presets is very significant.



Summary of laptop operation and setup
Laptop mode “Normal” “Fast” “Extreme”
Declared GPU Speed ​​(Boost) and Memory Speed 1260 MHz, 10.8 Gbps 1310 MHz, 10.9 Gbps 1360 MHz, 11 Gbps
The Witcher III Real GPU Clock: Min, Max, Average 1425 MHz 1515 MHz 1635 MHz
1485 MHz 1555 MHz 1710 MHz
1449 MHz 1554 MHz 1643 MHz
Average frequency of all CPU cores 2.5 GHz 2.7 GHz 2.9 GHz
Maximum noise level 41.7 dBA 41.7 dBA 48.3 dBA
Average Power: GPU, CPU 89.5W 99.6W 99.5W
17.4W 18 W 20W
GPU Temperature: Average, Maximum 73 °C 76 °C 69 °C
75 °C 77 °C 70 °C
CPU temperature: average, maximum 73 °C 75 °C 69 °C
80 °C 87 °C 86 °C
Performance, points
Test results in 3DMark Time Spy 6828 7345 7459
3DMark Fire Strike test results 15977 17370 17666
Test results in Unigine Superposition (1080p Extreme) 4255 4543 4604
Performance boost in benchmarks +8%, +9%, +7% +9%, +11%, +8%



“Regular”

“Fast”

“Extreme”

We are dealing with graphics in Max-Q design, although this fact is not mentioned anywhere on the manufacturer’s website. The frequencies of the GeForce RTX 2070 GPU are specifically “strangled” for the sake of energy efficiency, and in the default operating mode in the game The Witcher 3, the chip frequency varies from 1425 to 1485 MHz. As soon as the “Fast” mode was turned on, the GPU frequency increased by an average of 105 MHz. Well, the “Extreme” mode, in fact, activates the maximum fan speed – this is well shown by measurements of the noise level and temperature of PC components.

Noteworthy is the work of the central processor in games. The frequency of the 6-core Core i7-10750H does not exceed 3 GHz, which has a positive effect on heating and noise levels. Yes, the operation of the Predator Helios 300 is well audible, but this laptop cannot be called loud when the first two modes are turned on, because much noisier models often stay in the test lab.

Acer engineers decided to slightly increase the power limit of the Core i7-10750H, however, in serious resource-intensive programs that can load a 6-core processor by 45 watts or more, the chip frequency does not reach the maximum laid down by Turbo Boost technology. In Premiere Pro, for example, it drops to 2 GHz, and the average is 3.5 GHz. This pays off in long tests. The situation can be somewhat corrected by CPU downvolting, carried out using special software (“Extreme” + XTU in the table below).


Laptop Cooling Performance in Adobe Premiere Pro 2020
“Extreme” “Extreme” + XTU
CPU frequency Medium 3.5GHz 3.7GHz
CPU Temperature Maximum 78 °C 78 °C
Medium 73 °C 67 °C
Noise level Maximum 42.2 dBA 42.2 dBA
CPU Power Consumption Average 53.3W 44W
Test task execution time (less is better) 1211 s 996 s



“Extreme”

“Extreme” + XTU

⇡#Laptop performance

The previously tested Predator Helios 300 had a similar configuration: a 6-core Intel CPU and a GeForce RTX 2070 in a Max-Q design – the potential of such a bundle in games is well known.

Naturally, any laptop with a GeForce RTX 2070 on board is great for modern AAA projects in Full HD resolution. Even when using the maximum (or close to the maximum) graphics quality settings, the Predator Helios 300 in all games without exception gives a comfortable FPS.

Of course, to get a higher FPS in some games, you can lower the quality of the graphics. Not in all projects, the transition from the “High Quality” to “Maximum Quality” mode is accompanied by a noticeable improvement in the image to the naked eye. But the FPS drops sharply, yes.



Test results in games, Full HD, FPS
AVG 1% MIN
Multiplayer Games
World of Tanks enCore 155 110
Dota 2 112 60
Counter Strike: Global Offensive 237 57
PlayerUnknown’s Battlegrounds 138 97
Old but still popular games
The Witcher III: Wild Hunt 83 53
GTA V 73 56
The Elder Scrolls V: Skyrim Special Edition 124 70
(Relatively) modern games
Assassin’s Creed Odyssey 56 47
Far Cry New Dawn 80 60
Total War Three Kingdoms 57 43
Red Dead Redemption 2 50 35
Battlefield V 90 60
Metro: Exodus 50 31
Shadow of the Tomb Raider 82 63
Gears 5 73 50
DOOM Eternal 143 111
Horizon Zero Dawn 63 31



When comparing laptops with similar processors and graphics, you need to make a lot of reservations, because once again we are convinced that many factors affect the performance of a mobile CPU in a laptop, such as the efficiency of the cooling system and the success of the CPU instance itself, as well as the speed of those installed in the laptop storage devices. And we see that the Predator Helios 300 in some cases outperforms the MSI model equipped with exactly the same CPU.

Below are the results of testing the laptop in the PCMARK10 comprehensive benchmark.
In a number of tests (archiving, working with graphics and photo and video content, interaction with browsers, as well as office applications), the laptop drive plays an important role. In Helios, the main storage device is the Western Digital WDC PC SN730 SSD.

⇡#Laptop offline

The laptop comes with a 58 Wh lithium-ion battery. Such a battery was enough for the laptop to work in light scenarios for almost six hours. The display brightness can always be reduced, and then the Predator Helios 300 will work for another half an hour or an hour longer.



Battery life, screen brightness 200 cd/m2
Web 5 hours 42 minutes
View Video 5 hours 57 minutes



⇡#Conclusions

Everything that I once wrote about the 17-inch model, in fact, can be addressed to the 15-inch version of the Predator Helios 300. Acer has released a good laptop that does not have serious flaws. I note the good build quality and the ability to upgrade the device. The cooling system is configured so that it provides low temperatures for the main components of the laptop and does not work too loudly. Finally, the GeForce RTX 2070-level graphics (albeit in Max-Q design) are enough to comfortably play all modern games in Full HD resolution.

FAQ Acer predator helios 300 (ph315-53)

How does the 1920 x 1080 resolution IPS ComfyView display enhance the gaming experience on a notebook?

The 1920 x 1080 resolution IPS ComfyView display offers sharp and clear visuals with a wide viewing angle up to 178°, reducing glare and providing a comfortable viewing experience during extended gaming sessions.

What performance benefits does the 10th generation Intel® Core™ i7-10750H processor provide in gaming notebooks?

The 10th generation Intel® Core™ i7-10750H processor, clocked at 2.6GHz, delivers powerful performance for gaming, allowing you to maximize the efficiency in demanding games and multitasking scenarios.

How does the NVIDIA® GeForce® RTX™ 3060 enhance graphics in gaming laptops?

The NVIDIA® GeForce® RTX™ 3060 graphics card offers advanced ray tracing and NVIDIA DLSS technologies, ensuring high-quality, realistic graphics and smooth performance in modern games.

Why is 512GB SSD storage advantageous in gaming laptops?

512GB SSD storage provides ample space for a large game library and ensures faster data access and quicker game load times compared to traditional hard drives, enhancing the overall gaming experience.

What are the benefits of having 16GB RAM in a gaming notebook?

16GB RAM in a gaming notebook ensures smooth multitasking and efficient handling of memory-intensive games and applications, providing a seamless gaming experience.

How does Wi-Fi 6 (IEEE 802.11ax) improve online gaming on laptops?

Wi-Fi 6 (IEEE 802.11ax) offers faster and more stable internet connections, reducing latency and improving online gaming and streaming experiences.

What features does PredatorSense™ software offer to gamers?

PredatorSense™ software allows gamers to monitor their system, overclock, create macros, and adjust gaming settings, providing a customized and optimized gaming experience.

How does the 4th Gen AeroBlade 3D fan technology benefit Predator laptops?

The custom-engineered 4th Gen AeroBlade 3D fan technology in Predator laptops reduces noise while increasing airflow, ensuring efficient cooling and stable performance during intense gaming sessions.

Can Helios 300 gaming laptops connect to an external display?

Yes, Helios 300 gaming laptops can connect to an external display, providing an expanded gaming setup, suitable for both casual gaming and competitive esports platforms.

What advantages does the Intel i7-10750H processor offer for aspiring esports athletes?

The Intel i7-10750H processor provides high-speed performance and reliable processing power, essential for aspiring esports athletes who need to meet and match the demands of competitive gaming scenarios.

What are the benefits of having a 512 GB SSD in a gaming laptop?

A 512 GB SSD in a gaming laptop ensures faster boot times, quicker game loads, and efficient data transfer, enhancing the overall gaming experience.

How does the GeForce RTX™ graphics card improve gaming performance?

The GeForce RTX™ graphics card offers advanced gaming capabilities, including ray tracing and AI-enhanced graphics, providing a more immersive and realistic gaming experience.

What advantages does an Intel Core i7 processor offer in gaming laptops?

An Intel Core i7 processor delivers high-speed performance and efficient processing, crucial for handling demanding games and multitasking without lag.

Why is the NVIDIA GeForce RTX 3060 a popular choice for gaming laptops?

The NVIDIA GeForce RTX 3060 is favored in gaming laptops for its excellent balance of performance and power efficiency, offering superior graphics quality and smooth gameplay.

How important is it to monitor your system in a gaming laptop?

Monitoring your system in a gaming laptop is vital for keeping track of performance metrics, temperature, and system health, ensuring optimal performance during gaming sessions.

What type of tech support is typically available for gaming laptops like Helios 300?

Tech support for gaming laptops like Helios 300 usually includes troubleshooting, hardware and software assistance, and guidance for optimizing gaming performance.

How does the design of Predator laptops reduce noise while increasing airflow?

Predator laptops utilize custom-engineered cooling technology, which efficiently reduces noise while increasing airflow, preventing overheating during intense gaming sessions.

What are the benefits of 2060 graphics in gaming laptops?

2060 graphics in gaming laptops offer a solid gaming performance, supporting modern gaming features like ray tracing and providing a good balance between quality and power consumption.

How does overclocking benefit gamers?

Overclocking allows gamers to increase the processing speed of their gaming laptop’s components, providing enhanced performance and smoother gameplay in demanding games.

What makes esports platforms unlike any other for gaming laptops?

Esports platforms unlike any other provide a competitive gaming environment, requiring gaming laptops with high-performance hardware, fast response times, and reliable internet connectivity like IEEE 802.11ax Wi-Fi, to meet the demands of professional-level gaming.

Share the material in social networks:
Laptop Master

Laptops are an essential tool for students, professionals, and anyone who needs a portable device for work or entertainment.

In this site, we'll be taking a closer look at some of the best laptops currently available on the market. We'll be focusing on factors such as performance, design, and price to provide you with a comprehensive overview of each laptop.

Rate the author
( 2 reviews,
average 5 of 5 )
Most Popular Articles
